Straight 3Pin M12 Male Socket A Code Rear Mount Solder for 22AWG 24AWG 26AWG
Attributes:
Pin Number: 3Pin 4pin 5pin 6pin 8pin 12pin 17pin
Coding: A Code B Code D Code
Gender: Male
Orientation: Straight
Mounting Feature: Rear Mount Solder for 22AWG 24AWG 26AWG
Features:
The M12 connector is a circular connector with a 12-mm locking thread that is used primarily in factory automation applications
for actuators, sensors, industrial ethernet, and Fieldbus. M12 connectors are designed for wash down and corrosive environments.
Pin Number: 3Pin 4pin 5pin 6pin 8pin 12pin 17pin
Coding: A Code B Code D Code
Gender: Male
Orientation: Straight
Mounting Feature: Rear Mount Solder for 22AWG 24AWG 26AWG
Features:
The M12 connector is a circular connector with a 12-mm locking thread that is used primarily in factory automation applications
for actuators, sensors, industrial ethernet, and Fieldbus. M12 connectors are designed for wash down and corrosive environments.
Basic Specifications
| M Series | |
| Model Number | M12 |
| Type | Male Socket |
| Product name | M12 Connector |
| Contacts | 3Pin 4pin 5pin 6pin 8pin 12pin 17pin |
| Gender | Male |
| Code | A Code B Code D Code |
| Orientation | Straight |
| Connector type | Socket |
| Mounting Type | Solder for 22AWG 24AWG 26AWG |
| Waterproof rate | IP67 |
| Material of contact | Copper |
| Temperature Range | -25~80℃ |
